The solar generating system, to supply the power, is composed with the photovoltaic(pv) modules arrayed
in series/parallel, storage battery, power controller, and ac/dc converter.
The characteristics of the solar generating is, firstly, the solar beam is an eternal energy.
The fossil fuel is in limited sources, but the solar energy will last almost semi-eternally.
Secondly, it is a clean energy source. Because the solar battery converts the beam directly to electricity that
it does not produce the environment-destroying noxious emissions such as from the fossil burring generating systems.
And also, no noise, none at all.
ere almost similar to the propeller of the airplanes.
But nowadays, it is greatly improved, and progressed to fit to the purpose, and became the ones which we can see around.
Your requiring any specifications can be complied.
|
The merits of the solar generating system;
 Highly modular, the plant economy is not a strong function.
Power output matches very well with peak load demands
The energy source is clean and unlimited.
Can be set up at the required places, in required sizes.
Easy maintenance and repair, manless operation possible.
Long operating life(Over 20 years).
|
 |
The shortcoming of the solar generating system;
Have to depend on the locally different volume of sunshine.
Wide space needed because of the thin energy density.
The setting up place is limited.
High setting up cost.
High initial setting up cost, and high early stage generating cost.
|
|
 |
|
The Power from the Photovoltaic is supplied to Grid-Connected Systems.
MPPT(Maximum Power Point Tracking), IGBT, DSP, LCD(TOUCH SCREEN), Boost
|
| Series |
Grid Voltage |
Nominal AC Frequency (Hz) |
Volume of Rated Power (kW) |
PDF |
| SKY30-S |
Single phase 220V |
60/50 |
3 (Boost) |
 |
| SKY50-S |
Single phase 220V |
60/50 |
5 (Boost) |
|
| SKY10K-S |
3 phase 220/380V |
60/50 |
10 |
|
| SKY100K-S |
Under Development |
100 |
|
|
 |
 |
 |
|
|
